With the development of transport, construction and other industries,
customers put forward higher requirements for the performance of the crusher,
especially the crusher's control technology for the discharge particle size. Jaw
crusher, as one of the commonly used crushing equipments, is very mature in
discharge size control technology. Can the discharge size of 69 jaw crusher be
controlled within 50mm? In this paper, we will discuss the working principle of
the equipment and the influence of the crushing chamber structure, the discharge
size control technology, as well as the field application of 69 Jaw Crusher.
I. Influence of Jaw Crusher Cavity Structure on Discharge Size Control
Jaw crusher mainly crushes various kinds of stone materials by mutual extrusion between jaw plates. During the crushing process, the material firstly enters into the crushing chamber from the inlet, and then is subjected to extrusion, impact and shear force from all sides, and finally crushed into smaller particle size, and discharged smoothly from the outlet.
The structure of the crushing chamber is one of the important factors affecting the particle size of the discharged material. For the jaw crusher, the distance between the jaw plates in the crushing chamber and the movement track have a greater impact on the crushing degree of the stone. Reasonable setting of the distance and movement track between jaw plates in the crushing chamber can ensure even and large crushing capacity while effectively controlling the discharge particle size.
II. Discharge particle size control technology: the method of adjusting the size of discharge opening
With the continuous refinement of technology, jaw crushing discharge control technology is not only limited to manual adjustment methods, hydraulic adjustment to accurately achieve fine adjustment of the discharge opening is both time-saving and energy-saving, is the favourite of many users.
Jaw crusher discharge size control methods
1, gasket adjustment: the adjustment gasket is generally located behind the elbow plate seat in the adjustment seat. When the discharge opening needs to be adjusted, the number of shims can be increased or decreased, and the total thickness of shims can be changed, so that the front and rear position of the elbow plate can be changed, and the front and rear position of the lower part of the movable jaw can be moved, so as to realise the change of the size of the discharge opening.
2、Hydraulic adjustment: Hydraulic adjustment mode is to change the adjusting screw in the mechanical adjustment mode to a hydraulic cylinder, and at the same time, the adjustment of the tension spring is also realised through the hydraulic cylinder, so that the automatic adjustment of the discharge opening is realised, which is convenient and labour-saving.
In addition, the jaw crusher discharge opening also derived from the mechanical adjustment, hydraulic cylinder adjustment and so on, there is very convenient. People can choose according to their needs. In addition to adjusting the size of the discharge opening, the parameters of the crusher such as the rotation frequency and the feeding volume will also affect the grain size of the discharged material. Reasonable setting of these parameters can further control the discharge particle size and meet the crushing needs in different scenarios.
III. 69 Jaw Crusher Field Application
In the field application, the discharge size needs to be adjusted according to different crushing tasks. Through the reasonable setting of the jaw crushing chamber structure and the size of the discharge opening, the 69 Jaw Crusher can achieve fine control of the discharge size within a certain range. Especially for some specific engineering requirements, such as the preparation of roadbed filler, it is very critical to control the discharge size within 50mm.
The ability of the 69 Jaw Crusher to control the particle size within 50mm depends on a number of factors. In practice, according to different crushing tasks and material characteristics, flexible use of the discharge size control technology can meet the needs of the project, improve production efficiency, reduce energy consumption, and ultimately achieve good economic and social benefits.
