During the use of impact crushers, abnormal vibration and heating of bearings often occur. I don’t know how to deal with them. The following stone crusher manufacturer will analyze them in detail.

Click here to learn about impact crusher knowledge

1. Abnormal vibration of impact crusher

1. It means that the material is too large. You can check the feed size.

2. Uneven wear means that the impact hammer head needs to be replaced.

3. The rotor is unbalanced and needs to be adjusted.

4. Improper foundation treatment requires checking the anchor bolts and strengthening them.

2. Heating of impact crusher bearings

1. It means that the bearing is short of oil and needs to be refueled in time. Of course, too much refueling will also cause the bearing to heat up. Be sure to check the oil level when refueling.

2. The bearing is damaged and the bearing should be replaced in time.

3. The upper cover is too tight. Adjust the bolts to a moderate tightness.

3. The particle size of the material discharged from the impact crusher is too large

1. It indicates that the hammer head is worn and needs to be adjusted or replaced.

2. The gap between the hammer head and the impact plate is too large, generally adjusted to 15-20mm.

3. The feed particle size is too large and will also affect the particle size of the material.

4. The crusher belt flips

1. It indicates that the belt is worn and the V-belt needs to be replaced.

2. Due to the problem of belt transmission assembly, the pulley needs to be adjusted on the same plane.

3. Be sure to pay attention to the quality of the V-belt itself.
